Must EH55-H1KS 1KVA Online UPS
  • Rear view of the Must EH55-H1KS online UPS showing power sockets, USB/RS232 ports, EPO slot, and battery connectors.

Must EH55-H1KS 1KVA Online UPS

Price To be announced
Status Up Coming
Product Code 46010
Brand Must

Key Features

  • Model: EH55-H1KS
  • Rated Capacity: 1KVA/1KW
  • Input Voltage: 208/220/230/240VAC
  • Battery Type: Lead Acid Battery
  • Battery Capacity: 3× 12V/(36VDC)
  • View More Info
stars 450 Star Points
Up Coming

Specification

Main Feature
Capacity1KVA / 1KW
Display TypeLCD 2×8, 4 buttons + 4 LEDs; RS-232; USB; optional SNMP/RS485; EPO optional
Load CapacityAC Mode: 95.5% @ 220VAC
Battery Mode: 91.5% @ Rated Battery Voltage
Input Voltage208 / 220 / 230 / 240 VAC
Output Voltage208 / 220 / 230 / 240 VAC
Noise Level≤45 dB
BatteryBattery type: Lead Acid Battery
Rated Battery Voltage: 36VDC
Battery Spec: 3 × 12V / (36VDC)
Input Features
Frequency50/60±6Hz (Default), ±10Hz (Settable)
Power FactorL+N+PE
Voltage Range110~300VAC
Output Features
Voltage Range208/220/230/240VAC
Power FactorL+N+PE
Physical Specification
Dimension635 × 193 × 560 mm
Weight20.5 kg
Manufacture Warranty
Warranty1 Year (Box Mandatory While Claiming)
Under the following conditions, the warranty would not be provided:
• UPS burning due to thunder, abnormal overload, insect entrance and others.
• If ambient temperature should not be maintained at 20 to 26 degrees Celsius with proper dehumidification. (24/7)
• If the product is placed in a dusty and damp place.
• In the absence of Generator connectivity Without proper battery charge, the warranty will be void.
• Battery swelling and overcharging due to the wrong system voltage setting of the UPS.

Description

Must EH55-H1KS 1KVA Online UPS

The Must EH55-H1KS 1KVA Online UPS is a high-performance, dependable power backup solution designed to provide continuous, stable, and clean energy to important systems. This Must Online UPS, with a rated capacity of 1KVA/1KW, is intended for use in offices, small data centers, and home networks that demand continuous power delivery and protection against voltage fluctuations. Built with true double-conversion technology, it delivers continuous power with no transfer time, making it suitable for delicate equipment. The Must EH55-H1KS 1KVA Online UPS is highly precise, with an output voltage accuracy of ±1% and frequency stability of ±0.1% throughout battery operation, ensuring optimal performance in all load scenarios. The Must 1KVA Online UPS has excellent efficiency of 95.5% in AC mode at 220V and 91.5% in battery mode, providing energy-efficient performance while minimizing power losses. It has a large input voltage range of 110-300V and a frequency range of 50/60Hz (±10Hz settable), making it easily adaptable to different power situations. The Must EH55-H1KS 1KVA Online UPS, which has three 12V lead-acid batteries and a total voltage of 36VDC, provides steady and long-lasting battery backup for vital equipment. Its sophisticated charging mechanism supports both two-stage and three-stage charging, with adjustable charging currents ranging from 1A to 2A, prolonging battery life and enhancing energy efficiency. An LCD display enhances user convenience. The Must EH55-H1KS 1KVA Online UPS gives real-time data on load, voltage, and operating status via LED indicators and four control buttons. Connectivity options include RS-232, USB, and optional SNMP/RS485 for smart monitoring, as well as a safety feature called emergency power-off (EPO). The Must Online UPS operates efficiently in temperatures ranging from 0°C to 40°C and humidity levels up to 95%. It has a modest noise level of ≤45dB, making it suited for both professional and domestic environments. The Must EH55-H1KS Online UPS is a reliable alternative for those that require powerful protection and consistent energy performance in a modern power management system.

Buy Must EH55-H1KS 1KVA Online UPS from CCTV Shop

In Bangladesh, you can get original Must EH55-H1KS 1KVA Online UPS From CCTV Shop. We have a large collection of latest Must Online UPS to purchase. Order Online Or Visit your Nearest CCTV Shop Shop to get yours at lowest price. The Must EH55-H1KS 1KVA Online UPS comes with 1 year warranty.

Under the following conditions, the warranty would not be provided:

• UPS burning due to thunder, abnormal overload, insect entrance and others.

• If ambient temperature should not be maintained at 20 to 26 degrees Celsius with proper dehumidification. (24/7)

• If the product is placed in a dusty and damp place.

• In the absence of Generator connectivity Without proper battery charge, the warranty will be void.

• Battery swelling and overcharging due to the wrong system voltage setting of the UPS.

What is the price of Must EH55-H1KS 1KVA Online UPS in Bangladesh?

The latest price of Must EH55-H1KS 1KVA Online UPS in Bangladesh is 0৳. You can buy the Must EH55-H1KS 1KVA Online UPS at best price from our website or visit any of our showrooms.
